Lithium-ion battery trucks

The new releases include several new pallet and stacker trucks and five counterbalance trucks ranging from 1.4 to 1.8 tonnes where both the truck and battery will be covered by the Linde CE mark having passed extensive safety and functional testing.

The new Linde T16L ION pallet truck and Linde D08 ION double stacker come with varying battery sizes and charging times. The latest pallet truck is available with an easy-charge system comprising a side mounted battery connector so that operators only need to plug the charging cable into an external socket on the truck instead of opening lids or flaps. This will make opportunity charging more convenient.

The design of the pallet and double stacker trucks centre on operator comfort and productivity. Both feature an ergonomic lift function which raises the load arms, in the case of the T16L ION, by 635mm making it easier for operators to pick up and position heavier loads and allow the truck to be used as a mobile work bench. The D08 ION on the other hand is designed as a double stacker with a selection of masts offering lift heights up to 2110mm allowing the truck to handle two loads at the same time for loading or unloading double deck trailers.

David Bowen, Linde’s UK warehouse truck product manager, said: “We’ve fitted a range of safety and comfort features including spring loaded castor-wheels on the D08 ION for stability and traction when operating over dock levellers, a creep speed option on both models for operation in confined spaces and buzzer alerts to replace horns in noise-sensitive environments.”

The T16L is also available with an automatic lifting and lowering function using light sensors attached to the truck’s mast to detect loads. The lift mast automatically lifts the forks avoiding operators having to bend down. All lifting functions can be controlled manually to  save time while unloading.

During charging, the traction circuit is locked out for safety.

In addition to the pallet and double stacker trucks, Linde has introduced five new lithium-ion counterbalance trucks to its range. These new models have a variety of safety features including a centralised control system and shock sensor to monitor impact and possible damage.
